Operating Temperature ..................................................... -40° to +150°F (-40° to +65°C)
Non-operating (Storage) Temperature............................... -40° to +158°F (-40° to +70°C)
Current Draw ...................................................................0.20 mA (average), 30 mA (peak) at 3.3 VDC
Solar Power Panel ...........................................................0.5 Watts
Battery .............................................................................CR-123 3-Volt Lithium cell
Battery Life (3-Volt Lithium cell) ........................................8 months without sunlight - greater than 2 years depending on solar
charging
Wind Speed Sensor .........................................................Wind cups with magnetic detection
Wind Direction Sensor .....................................................Wind vane with magnetic encoder
Rain Collector Type .........................................................Tipping spoon, 0.01" per tip (0.2 mm with metric rain cartridge, Part
No. 7345.319), 18.0 in2 (116 cm2) collection area
Temperature Sensor Type ................................................PN Junction Silicon Diode
Relative Humidity Sensor Type .........................................Film capacitor element
Housing Material ...............................................................UV-resistant ABS & ASA plastic
ISS Dimensions ................................................................12.95" x 5.75" x 13.40" (329 mm x 146 mm x 340 mm)
Package weight: ...............................................................5.44 lbs (2.47 kg)
